2. Technical specifications
2.1 Basic technical parameters
|
Working power supply |
three-phase five-wire AC 380V |
2.2 Equipment appearance parameters
|
Dimensions |
1600mm*750mm*1870mm |
|
Weight |
≤300kg |
3. Product introduction
3.1 Product module section|
No. |
Name |
Quantity |
|
1 |
Maximum demand meter |
1 |
|
2 |
Power circuit breaker |
1 |
|
3 |
Reactive power controller |
1 |
|
4 |
Three-phase power supply unit |
1 |
|
5 |
Counter |
1 |
|
6 |
Power factor meter |
1 |
|
7 |
Mechanical ammeter |
1 |
|
8 |
Mechanical voltmeter |
1 |
|
9 |
Three-phase counter |
1 |
3.2 Product Motor Part
|
No. |
Name |
Quantity |
|
1 |
Three-phase asynchronous motor |
1 |
3.3 Product chassis
|
No. |
Name |
Quantity |
|
1 |
Resistive load box |
1 |
|
2 |
Inductive load box |
1 |
|
3 |
Switchable capacitor battery |
1 |
3.4 Product accessories
|
No. |
Name |
Quantity |
|
1 |
4mm electrical safety connection cable (1m-blue) |
5 |
|
2 |
4mm electrical safety connection cable (1m-two-color) |
2 |
|
3 |
4mm electrical safety connection cable (1m-red) |
5 |
|
4 |
4mm electrical safety connection cable (1m-yellow) |
5 |
|
5 |
4mm electrical safety connection cable (1m-green) |
5 |
|
6 |
4mm electrical safety connection cable (1m-black) |
10 |
|
7 |
4mm electrical safety connection cable (0.25m-blue) |
5 |
|
8 |
4mm electrical safety connection cable (0.25m-two-color) |
8 |
|
9 |
4mm electrical safety connection cable (0.25m-green) |
5 |
|
10 |
4mm electrical safety connection cable (0.25m-red) |
5 |
|
11 |
4mm electrical safety connection cable (0.25m-yellow) |
5 |
|
12 |
Industrial waterproof plug (female) |
1 |
|
13 |
European power cord |
6 |
|
14 |
Equipment power cord |
1 |
|
15 |
Socket strip |
1 |
|
16 |
Hexagonal wrench |
1 |
|
17 |
Sensor |
1 |
|
18 |
Communication line |
1 |
|
19 |
Weight |
2 |
|
20 |
Fuse core (3A) |
5 |
|
21 |
Fuse tube (50mA and 5A) |
5 |
|
22 |
U-shaped bridge (K4-black) |
5 |
|
23 |
Stopwatch |
1 |
5. Product teaching experiment list
(1) Free compensation test (manual)
(2) Reactive compensation (automatic)
(3) Reactive power consumption experiment
(4) Active power consumption experiment
(5) Counter and power factor meter experiment (single phase)
(6) Counter and power factor meter experiment (two phase)
(7) Three-phase squirrel cage motor load characteristic experiment
