No |
Name |
|
1 |
Aluminum profile equipment rack |
|
2 |
monitor |
|
3 |
wooden desktop |
|
4 |
battery storage box |
|
5 |
Universal wheel |
|
6 |
servo motor |
|
7 |
Servo generator |
|
8 |
wooden storage table |
|
9 |
Wind Turbines |
|
10 |
Wind turbine bracket |
|
11 |
Inverter module |
|
12 |
AC load module |
|
13 |
Information input module |
|
14 |
Simulated solar modules |
|
15 |
Small wind turbine 370w module |
|
16 |
load module |
|
17 |
Power box module |
|
18 |
12v small power plant module |
|
19 |
Communication module |
|
20 |
Power module |
|
21 |
DC load module |
|
22 |
Servo motor driver module |
3.2 Accessories
|
No |
Name |
Qty |
|
1 |
Servo motor data cable |
1 |
|
2 |
Servo motor power cord |
1 |
|
3 |
HDMI high-definition cable |
1 |
|
4 |
Computer host power cord |
1 |
|
5 |
computer monitor power cord |
1 |
|
6 |
Simulation debugger |
1 |
|
7 |
multimeter |
2 |
|
8 |
European socket |
1 |
|
9 |
USB cable |
3 |
|
10 |
U-shaped fork (black and red) |
16 |
|
11 |
4mm safety plug with socket (yellow) |
8 |
|
12 |
4mm safety plug with socket (blue) |
8 |
|
13 |
4mm safety plug with socket (black) |
6 |
|
14 |
4mm safety plug with socket (red) |
6 |
|
15 |
4mm safety plug with socket (dual color) |
3 |
|
16 |
4mm safety connection cable (black) |
1 |
|
17 |
4mm safety connection cable (red) |
1 |
4. Experiment list
Experiment 1 Solar panel open circuit voltage test experiment
Lab 2 Understand the design and operation of modern small wind farms
Experiment 3 explores the basic physical principles of "from wind to waves"
Experiment 4 Off-grid system design for AC voltage generation
Experiment 5 Solar panel maximum power point test experiment
Experiment 6 explores an off-grid powered hybrid system using wind and photovoltaic systems
