I. Product Overview
1.1 Product Description
The speed control of pneumatic motors is mainly achieved by adjusting the flow and pressure of compressed air. When the flow of compressed air increases, the speed of the motor will increase accordingly; conversely, when the flow decreases, the speed will decrease. At the same time, changes in pressure will also have a certain impact on the speed.
1.2 Product Features
Pneumatic motors are small, light, simple in structure, and easy to install and maintain.
Pneumatic motors can efficiently convert the pressure energy of compressed air into rotary mechanical energy and output torque to drive various actuators to perform rotary motion.
II. Performance Parameter
2.1 Technical Parameters
Solenoid valve power supply parameters: two-wire DC 24V
Encoder power supply parameters: two-wire DC 24V
2.2 Dimensions and Weight
Dimensions: 400mm*300mm*220mm
Weight:<10kg
III. Product Component Names and Function Introduction
3.1 Product main part
|
No. |
Name |
Quantity |
|
1 |
Two-piece |
1 |
|
2 |
Proportional directional control valve |
1 |
|
3 |
Pneumatic motor |
1 |
|
4 |
Rotary encoder |
1 |
|
5 |
Coupling |
1 |
IV.Experiment list
Experiment 1 Analog output test experiment
